Features
- bestens für Edelstahlschränke und Bedienpulte geeignet
- für Indoor- und Outdooranwendungen
- wartungsfrei
- können in fast jeder Lage montiert werden
(Hinweis: abhängig von der Installation ist das Kondensatmanagement evtl. anzupassen)
Order Number 6205303 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress protection to EN 60 529 IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 3102 / 6155 / 6205 Cooling capacity 95F/95F 680 BTU Air volume flow (system / unimpeded) Ambient air circuit: 62 / 153 cfm
Cabinet air circuit: 90 / 153 cfmOperating temperature range -4°F - 149°F UL temperature range -20°C - 65°C Mounting Recessed Dimension H x W x D A = Height | B = Width | C = Depth
500 x 330 x 190 (130+60) mm Weight 38 lbs Cut out dimensions 472 x 302 mm Voltage / Frequency 120 V, 230 V Current 95F95F 2.1 A @ 120 V
1.1 A @ 230 VStarting current 3.2 A @ 120 V
1.7 A @ 230 VMax. current 2.2 A @ 120 V
1.2 A @ 230 VNominal power 95F95F 250 W Max. power 270 W Fuse 4 A (T) @ 120 V
3 A (T) @ 230 VConnection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files 2D - PDF Mounting template tg6205-metric-mounting-template.dwg Certification EC declaration Zertifizierung (UK) UKCA declaration Video Peltier enclosure cooling units Stainless steel AISI 316 (V4A) housing part no. 62053034 Verpackungsmaße 586.6 x 354 x 227 mm Bruttogewicht 20.5 kg Taric code 84158300
