Features
- der nanobeschichtete hydrophobe Kondensator erlaubt einen filterlosen Betrieb
- wartungsfrei
- für aggresive Umgebungen verschiedene Filteroptionen erhältlich
- einstellbare elektronische Steuerung mit Display
- Wandanbau
Cooling capacity 95F/95F 5560 BTU Cooling capacity 95F/122F 4500 BTU Compressor type Reciprocating compressor Refrigerant / GWP R134a / 1430 Refrigerant charge 420 g / 14.8 oz High / low pressure 25.5 / 6 bar
370 / 88 psigAir volume flow (system / unimpeded) Ambient air circuit: 280 / 500 cfm
Cabinet air circuit: 225 / 324 cfmOperating temperature range 68°F - 131°F Mounting Recessed Dimension H x W x D A = Height | B = Width | C = Depth
41 x 17.8 x 10.6 inch Weight 87 lbs. Cut out dimensions 15.5 x 36.8 inch Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Current 95F95F 4.6 A @ 50 Hz
5.1 A @ 60 HzStarting current 21.2 A Max. current 5.6 A Nominal power 95F95F 800 W @ 50 Hz
920 W @ 60 HzMax. power 1.17 kW Fuse 10 A (T) Short-circuit current rating 5 kA Connection Connection terminal block Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Zertifizierung (UK) UKCA declaration Video Installation of SoliTherm ComPact enclosure air conditioners Stainless steel housing part no. 43150026 Taric code 84158200
