Features
- Low noise, therefore particularly suitable for offices and data centers
- easy installation, push-fit connector
- low mounting depth inside the enclosure
- various clip options for add-on thermostats
- robust sheet metal structure, power coated
- fast & easy servicing outside enclosure
Quick Links
Operating Temperature Range -10°C - 55°C Air flow volume (system / unimpeded) 1300 m³/h Air flow unimpeded 1500 m³/h Mounting top mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
241 x 550 x 550 mm Weight 12.7 kg Cut out dimensions 410 x 410 mm Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.73 A Power consumption 168 W Filter class Optional Aluminium filter Noise level 55 dB(A) Connection 4 pole connector Datasheet Generate PDF CAD files STEP Certification EC declaration Taric code 84145915
