Features
- Low noise, therefore particularly suitable for offices and data centers
- easy installation, push-fit connector
- low mounting depth inside the enclosure
- various clip options for add-on thermostats
- robust sheet metal structure, power coated
- fast & easy servicing outside enclosure
Quick Links
Order Number 6996A4000 Brand Name SOLIFLEX Colour RAL 7035 Housing Material Mild steel, powder coated Ingress Protection IP 21 Note Airflow with aluminium filter (optional) 1300 m³/hr Approvals CE Operating Temperature Range -10°C - 55°C Air flow volume (system / unimpeded) 1300 m³/h Air flow unimpeded 1500 m³/h Mounting top mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
241 x 550 x 550 mm Weight 12.7 kg Cut out dimensions 410 x 410 mm Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.73 A Power consumption 168 W Filter class Optional Aluminium filter Noise level 55 dB(A) Connection 4 pole connector Datasheet Generate PDF CAD files STEP Certification EC declaration Taric code 84145915
