Air flow unimpeded IP 54 760 m³/h Operating Temperature Range -10°C - 55°C Static pressure 220 Pa Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
325 x 325 x 160.2 Weight 4.25 kg Cut out dimensions 291 +1.5 x 291 +1.5 Voltage / Frequency 120 V ~ 60 Hz Rated current 1.84 A Power consumption 215 W Degree of seperation IP 54 85% - DIN 24185 Wall thickness 1.5 - 2.5 mm Filter class (ISO 16890) G3 gemäß EN 779 Installation Elastic clips or by 4 self-threading screws Noise level 78.9 dB(A) Datasheet Generate PDF CAD files STEP Certification EC declaration Certification (UK) UKCA declaration With NEMA 3R protection part no. 4833A3030 Taric code 84145915 GTIN (EAN) 5350604100664
