Features
- suitable for stainless steel enclosures and control panels
- for indoor and outdoor applications
- maintenance free
- can be mounted in any position
(depending on the installation the condensate management may need to be adjusted)
Order Number 6105305 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Included Condensate drain socket Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Cooling capacity L35L35 100 W Rated COP 0.89 Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 128 / 213 m³/h
Cabinet air circuit: 46 / 90 m³/hMounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
280 x 350 x 160 mm Weight 11 kg Cut out dimensions 350 x 280 mm Voltage / Frequency 120 V, 230 V Starting current 1.6 A @ 120 V
0.8 A @ 230 VMax. current 1.2 A @ 120 V
0.6 A @ 230 VMax. power 139 W Fuse 2 A (T) @ 120 V
1 A (T) @ 230 VConnection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 61053054 Box dimension 314 x 436 x 183.5 mm Gross weight 13.1 kg Taric code 84158300
