Features
- suitable for stainless steel enclosures and control panels
- for indoor and outdoor applications
- maintenance free
- can be mounted in any position
(depending on the installation the condensate management may need to be adjusted)
Order Number 6105323 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) IP protection class to EN 60 529 IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6105 Cooling capacity L35L35 (EN14511-3) 100 W Air flow volume (system / unimpeded) Ambient air circuit: 128 / 213 m³/h
Cabinet air circuit: 46 / 90 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
281 x 353 x 175 (107+68) Weight 9.4 kg Voltage / Frequency 230 V ~ 50/60 Hz Current L35L35 0.5 A Starting current 0.8 A Max. current 0.6 A Nominal power L35L35 125 W Max. power 139 W Fuse 1 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 61053234 Box dimension 314 x 436 x 183.5 mm Gross weight 11.5 kg Taric code 84158300
Order Number 6105313 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) IP protection class to EN 60 529 IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6105 Cooling capacity L35L35 (EN14511-3) 100 W Air flow volume (system / unimpeded) Ambient air circuit: 128 / 213 m³/h
Cabinet air circuit: 46 / 90 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
281 x 353 x 175 (107+68) mm Weight 9.4 kg Voltage / Frequency 120 V ~ 60 Hz Current L35L35 1.0 A Starting current 1.6 A Max. current 1.2 A Nominal power L35L35 125 W Max. power 139 W Fuse 2 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 61053134 Box dimension 314 x 436 x 183.5 mm Gross weight 11.5 kg Taric code 84158300
Cooling capacity L35L35 (EN14511-3) 100 W Air flow volume (system / unimpeded) Ambient air circuit: 128 / 213 m³/h
Cabinet air circuit: 46 / 90 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
281 x 353 x 175 mm Weight 11 kg Cut out dimensions 350 x 280 mm Voltage / Frequency 230 V ~ 50/60 Hz Current L35L35 0.5 A Starting current 0.8 A Max. current 0.6 A Nominal power L35L35 125 W Max. power 139 W Fuse 1 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 61053254 Box dimension 314 x 436 x 183.5 mm Gross weight 13.1 kg Taric code 84158300
Cooling capacity L35L35 (EN14511-3) 100 W Air flow volume (system / unimpeded) Ambient air circuit: 128 / 213 m³/h
Cabinet air circuit: 46 / 90 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
281 x 353 x 175 mm Weight 11 kg Cut out dimensions 350 x 280 mm Voltage / Frequency 120 V ~ 60 Hz Current L35L35 1.0 A Starting current 1.6 A Max. current 1.2 A Nominal power L35L35 125 W Max. power 139 W Fuse 2 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files 61053x5.stp Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 61053154 Box dimension 314 x 436 x 183.5 mm Gross weight 13.1 kg Taric code 84158300
