Features
- suitable for small enclosures and small control panels
- for indoor and outdoor applications
- maintenance free
- can be mounted in any position
(depending on the installation the condensate management may need to be adjusted)
Cooling capacity L35L35 (EN14511-3) 75 W Air flow volume (system / unimpeded) Ambient air circuit: 116 / 306 m³/h
Cabinet air circuit: 58 / 182 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
250 x 203 x 160 (86+74) mm Weight 5.2 kg Cut out dimensions 210 x 160 mm Voltage / Frequency 24 V DC Current L35L35 4.6 A Starting current 6.9 A Max. current 5.3 A Power consumption 110 W Max. power 127 W Fuse 8 A (T) Connection 6 pole terminal block Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 30753034 Taric code 84158300
Cooling capacity L35L35 (EN14511-3) 75 W Air flow volume (system / unimpeded) Ambient air circuit: 116 / 306 m³/h
Cabinet air circuit: 58 / 182 m³/hOperating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Mounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
350 x 217 x 157 mm Weight 5.2 kg Cut out dimensions 210 x 160 mm Voltage / Frequency 24 V DC Current L35L35 4.6 A Starting current 6.9 A Max. current 5.3 A Power consumption 110 W Max. power 127 W Fuse 8 A (T) Connection 6 pole terminal block Datasheet Generate PDF Instruction manual Generate PDF CAD files 3075305.stp Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 30753034 Taric code 84158300
