Features
- modern industrial design
- maximum cooling power with minimum space
- digital controller with display
- microchannel condenser allows significant reduction in refrigerant charge resulting in a lower CO₂ equivalent
- temperature range 5˚C - 55˚C
- built-in electrical condensate evaporator
- RS 485 MODBUS interface included
Quick Links
Cooling capacity L35L35 (EN14511-3) 850 W Cooling capacity L35L50 (EN14511-3) 600 W Compressor type Rotary piston Refrigerant / GWP R134a / 1430 Refrigerant charge 140 g / 4.94 oz. High / low Pressure 28 / 6 bar
406 / 87 psigAir flow volume (system / unimpeded) Ambient air circuit: 850 m³/h
Enclosure air circuit: 645 m³/hOperating Temperature Range 5°C - 55°C Mounting Roof mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
412 x 595 x 395 mm Weight 32 kg Voltage / Frequency 230 V ~ 50/60 Hz Current L35L35 2.3 / 2.5 A Starting current 6.0 A Max. current 3.1 A Nominal power L35L35 505 W Fuse 15 A (T) Short-circuit current rating 5 kA Connection 4 pole connector for power
5 pole connector for signals
3 pole connector for RS 485 MODBUSDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP2D - PDF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 950800S62 Taric Code 84158200
Cooling capacity L35L35 (EN14511-3) 850 W Cooling capacity L35L50 (EN14511-3) 600 W Compressor type Rotary piston Refrigerant / GWP R134a / 1430 Refrigerant charge 140 g / 4.94 oz. High / low Pressure 28 / 6 bar
406 / 87 psigAir flow volume (system / unimpeded) Ambient air circuit: 850 m³/h
Enclosure air circuit: 645 m³/hOperating Temperature Range 5°C - 55°C Mounting Roof mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
412 x 595 x 395 mm Weight 36.5 kg Voltage / Frequency 400/460 V - 50/60 Hz 2~ Current L35L35 1.2 A Starting current 4 A Max. current 1.6 A Nominal power L35L35 537 / 617 W Max. power 719 W Fuse 15 A (T) Short-circuit current rating 5 kA Connection 4 pole connector for power
5 pole connector for signals
3 pole connector for RS 485 MODBUSDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP2D - PDF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 950820S62 Taric Code 84158200
