Features
- only 110 mm deep,ideal for smaller enclosures
- protection class IP 54
- completely filterless, thus maintenance free
- wall mounted or recessed
- NEMA 4X covers for stainless steel models
Quick Links
Order Number 42699582 Brand Name SLIMLINE Housing Material Stainless steel AISI 304 (V2A) IP protection class to EN 60 529 IP 54 / TYPE 12 Note With Master / Slave Function Approvals CE, cURus, cULus Accessories NEMA 4X Cover 4269 Cooling capacity L35L35 (EN14511-3) 500 W @ 50 Hz
520 W @ 60 HzCooling capacity L35L50 (EN14511-3) 160 W @ 50 Hz
180 W @ 60 HzEER L35L35 1.0 Compressor type Rotary piston compressor Refrigerant / GWP R 513A / 630 Refrigerant charge 142 g / 5 oz High / low Pressure 35 / 30 bar
290 / 188 psigAir flow volume (system / unimpeded) Ambient air circuit: 250 / 650 m³/h
Cabinet air circuit: 125 / 250 m³/hOperating Temperature Range 10°C - 50°C Mounting Wall mounted / Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
635 x 330 x 110 mm Weight 15.8 kg Cut out dimensions 581 x 301 mm Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Current L35L35 2.2 A @ 50 Hz
2.2 A @ 60 HzStarting current 5.8 A Max. current 2.7 A Nominal power L35L35 460 W @ 50 Hz
500 W @ 60 HzMax. power 600 W Fuse 6 A (T) Short-circuit current rating 5 kA Rated current compressor 5.2 A Full load current fans 2.8 A Connection Connection terminal block Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF external Certification EC declaration Certification (UK) UKCA declaration Video Service Video Part 1 A Wet Cleaning (small units)Service Video Part 2 - Dry cleaning Instructions Cleaning instructionCleaning instructions Type Plate 42699582_xxxx.pdf Box dimensions 680 x 400 x 155 mm Gross weight 19 kg Taric code 84158200 GTIN (EAN) 5350604370418
